RC Series R&O/AW Synthetic Gear and Bearing Oil

AMSOIL RC Series R&O/AW Synthetic Gear and Bearing Oil is formulated with high-quality synthetic base stocks and additive systems that effectively reduce wear and protect equipment by maintaining viscosity, resisting thermal and oxidative breakdown, inhibiting rust and resisting the degrading effects of water.

---

Non-detergent, ashless anti-wear additives provide an additional layer of protection against wear in severe conditions while antioxidants increase oxidation resistance and extend lubricant life. Rust inhibitors protect critical components against corrosion in the presence of water or process contaminants and foam suppressants help prevent foaming that can compromise film strength.

---

AMSOIL RC Series Oil is shear-stable and oxidation-resistant, helping prevent viscosity loss from mechanical shear and viscosity increase from oxidation. RC Series Oil re-mains fluid at cold temperatures, providing easier startups, quick lubrication circulation and limiting the need for sump heaters. At higher temperatures, RC Series Oil main-tains a thick lubricating film, reducing metal-to-metal contact and component wear.

RC Series Oil provides hydrolytic stability (stability in the presence of water) and  demulsibility (ability to separate from water), increasing lubricant life, helping prevent oil/water emulsions and allowing reservoirs to be drained of water.

---

ISO 32, 46 and 68 viscosity-grade RC Series Oils (RCH, RCI, RCJ) provide supe-rior protection in high- and low-pressure gear, vane and piston hydraulic systems, compressors, high-speed bearings, small gear sets, high-speed gears and many other industrial applications. RC Series Oil, meets AGMA specifications for R&O gear oil for the lubrication of intermediate-speed equipment where mild shock-loading and intermittent service are involved. These applications include machine tools, roller chains, gear reducers, cone drives, large motor bearings, medium-speed ball and roller bearings, blowers and worm gear sets. Consult the manufacturer for proper viscosity recommendations.

---

AMSOIL RC Series Synthetic Oil is primarily recommended for gear and bearing applications and circulating systems requiring R&O or anti-wear additive technology. The appropriate viscosity of AMSOIL RC Series Oil meets or exceeds the following hydrau-lic oil applications or requirements:

• Denison HF-0, HF-1 and HF-2

• Vickers M-2950-S and I-286-S

• Cincinnati Milacron P-68, P-69 and P-70

• U.S. Steel 127 and 136

• Ford M-6C32

• GM LH-04-1, LH-06-1 and LH-15-1

• Lee Norse 100-1

• Jeffrey No. 87

• BF Goodrich 0152

• Commercial Hydraulics

• AGMA R&O Synthetic Gear Oil specifications

Note: AMSOIL RC Series Oil is not designed for applications requiring extreme-pressure (EP) agents. For EP-fortified  lubricants, refer to AMSOIL SG Series Gear Oil.

---

The ability of RC Series Oil to extend drain intervals is subject to operating conditions and maintenance practices and should be monitored by oil analysis.

---

Although AMSOIL lubricants are compatible with mineral

oil-based lubricants, for optimum performance it is recom-mended that the system be thoroughly drained and cleaned, if warranted.
